Cold Rolled Grain Crgo Electrical Steel Grade H-0 For Wound Cores Or Uni-Cores Transformers

MOQ:	1
Price:	consult
Standard Packaging:	Standard export package for ocean transportation
Delivery Period:	5 days
Payment Method:	L/C, T/T, Western Union, MoneyGram
Supply Capacity:	200Ton/week

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

Certification

SGS，CE,UL

Model Number

H-0

Document

Product Brochure PDF

HS Code:

72251100

Trademark:

Baosteel; WISCO; Nippon Steel; JFE; AK

Bending Angle:

≥90°

Bending Test:

No Crack

Coating:

Electro Galvanized, Hot Dip Galvanized

Coating Color:

RAL Color

Coating Thickness:

5-25um

Elongation:

≥3%

Impact Test:

No Crack

Length:

1000mm-6000mm

Material:

CRGO&CRNGO

Surface:

Bright, Matte

Surface Hardness:

≥50HV

Tensile Strength:

450-550Mpa

Thickness:

0.23mm-0.35mm

Grade:

M1, M2, M3, M4

Package:

Standard Export Packing

Width:

1000mm-1250mm

Type::

Oriented Silicon Steel

Standard::

GB, AISI, ASTM, DIN, JIS

Technique::

Cold Rolled

Shape::

Coil

Transport Package::

Standard Export Package For Ocean Transportation

Trademark::

Baosteel; WISCO; Nippon Steel; JE; AK

Minimum Order Quantity:

Price:

consult

Packaging Details:

Standard export package for ocean transportation

Delivery Time:

5 days

Payment Terms:

L/C, T/T, Western Union, MoneyGram

Supply Ability:

200Ton/week

Highlight:

crgo electrical steel

cold rolled grain oriented steel

crgo and crngo

Product Description

Oriented Electrical Steel Grade H-0 Used for Wound Cores or Uni-Cores Transformers

Basic Info.

Model NO.

H-0

Origin

China; Japan; American

HS Code

72251100

Production Capacity

5000mt/Month

Product Description

Ordering Instruction(for prime coils or slit coils):
1, Which Grade? if you do not know the exact grade, please tell us below:
1), What's the thickness of the material?
2), What's the core losses @1.7T/50Hz(or 60Hz), for Non-Oriented electrical steel, please tell the core cosses@ 1.5T/50Hz or 60Hz;
2, What's the desination or discharge port?
3, How about the quantity?

If any technical issue about the prime coils or related to cores, welcome to contact us anytime.

Detailed description as below:

Type	Grade	Thickness (mm)	Available width range(mm)	ID	Density (kg/dm³)	P17/50Max.Core Loss(W/kg)	B8Min.Induction(T)
Common Type	B23G110	0.23	700-1200	508	7.65	1.10	1.80
	B27G120	0.27				1.20	1.80
	B30G120	0.30				1.20	1.80
	B30G130					1.30	1.80
	B30G140					1.40	1.80
	B35G135	0.35				1.35	1.80
	B35G145					1.45	1.80
	B35G155					1.55	1.80
High Induction Type	B23P090	0.23				0.90	1.87
	B23P095					0.95	1.87
	B23P100					1.00	1.87
	B27P095	0.27				0.95	1.88
	B27P100					1.00	1.88
	B27P110					1.10	1.88
	B30P100	0.30				1.00	1.88
	B30P105					1.05	1.88
	B30P110					1.10	1.88
	B30P120					1.20	1.88
	B35P135	0.35				1.35	1.88
	B35P155	0.35				1.55	1.88
Domain Refined High Induction Type	B23R080	0.23				0.80	1.87
	B23R085					0.85	1.87
	B23R090					0.90	1.87
	B27R090	0.27				0.90	1.87
	B27R095	0.27				0.95	1.87
NOTE:
Detecting Basis GB/T3655-2000
P17/50 means core loss of sample per kg at max.magnetic induction 1.7T and frequency 50HZ
B8 means magnetic induction corresponding to 800A/m magnetic field intensity

Cold Rolled Grain Crgo Electrical Steel Grade H-0 For Wound Cores Or Uni-Cores Transformers 0

Cold Rolled Grain Crgo Electrical Steel Grade H-0 For Wound Cores Or Uni-Cores Transformers 1

Cold Rolled Grain Crgo Electrical Steel Grade H-0 For Wound Cores Or Uni-Cores Transformers 2

Cold Rolled Grain Crgo Electrical Steel Grade H-0 For Wound Cores Or Uni-Cores Transformers 3
