Crgo Oriented Electrical Steel Grade 20r060 Used For Uhv Transformers
  • name
  • name
  • name
  • name
  • name
  • name
  • name
  • name
  • name
  • name
  • name
  • name
  • name
  • name
  • name
  • name
  • name
  • name

Crgo Oriented Electrical Steel Grade 20r060 Used For Uhv Transformers

MOQ: 1
Price: consult
Standard Packaging: Standard export package for ocean transportation
Delivery Period: 5 days
Payment Method: L/C, T/T, Western Union, MoneyGram
Supply Capacity: 200Ton/week
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
JC
Certification
SGS，CE,UL
Model Number
B20R060
Document
Product Brochure PDF
HS Code:
72251100
Trademark:
Baosteel; WISCO; Nippon Steel; JFE; AK
Bending Angle:
≥90°
Bending Test:
No Crack
Coating:
Electro Galvanized, Hot Dip Galvanized
Coating Color:
RAL Color
Coating Thickness:
5-25um
Elongation:
≥3%
Impact Test:
No Crack
Length:
1000mm-6000mm
Material:
CRGO&CRNGO
Surface:
Bright, Matte
Surface Hardness:
≥50HV
Tensile Strength:
450-550Mpa
Thickness:
0.23mm-0.35mm
Grade:
M1, M2, M3, M4
Package:
Standard Export Packing
Width:
1000mm-1250mm
Minimum Order Quantity:
1
Price:
consult
Packaging Details:
Standard export package for ocean transportation
Delivery Time:
5 days
Payment Terms:
L/C, T/T, Western Union, MoneyGram
Supply Ability:
200Ton/week
Highlight:

oriented electrical steel

,

crgo electrical steel

,

crgo steel

Product Description

Oriented Electrical Steel Grade 20r060 Used for Uhv Transformers

Basic Info.

Model NO.
B20R060
Origin
China
HS Code
72251100
Production Capacity
5000mt/Month

Product Description

Ordering Instruction(for prime coils or slit coils):
1, Which Grade? if you do not know the exact grade, please tell us below:
1), What's the thickness of the material?
2), What's the core losses @1.7T/50Hz(or 60Hz), for Non-Oriented electrical steel, please tell the core cosses@ 1.5T/50Hz or 60Hz;
2, What's the desination or discharge port?
3, How about the quantity?

If any technical issue about the prime coils or related to cores, welcome to contact us anytime.


Detailed description as below:


Major Manufacturer BAOSTEEL, WISCO, Nippon Steel, JFE, AK
Grade CRGO:
20ZDKH75, B20P075, B20P070, B18R070
B23G110, B23G100, B23P100, B23R095, B23R090, 23ZH90,23QG090, B23R080
27Q120, 27QG100, 27QG095, B27P120, B27P100, B27P095
30Q130, 30Q120, 30QG105; B30G130, B30G120, B30P120, B30P105
35Q155, B35G155, 35Z155
CRNGO:
B35A270, B35A250, B35A230, B35A300, 35WW270,35WW250,35WW230
B50A800, B50A600, B50A470, B50A400, B50A310, B50A290, B50A250, B50A1300, B50A1000
Nominal thickness 0.18mm, 0.20mm, 0.23mm,0.27mm,0.30mm,0.35mm, 0.5mm
Coil ID 508mm
Weight 2MT~8MT
Standard EN 10106,IEC 60404-8-4,ASTM,DIN,GB,JIS
Form Cold Rolled Strip
Delivery Lead Time 7~15 days after T/T prepayment or L/C date
Packing Standard export package for ocean transportation
Application All kinds of transformer, reactor,filter,inverter

Specification of CRGO silicon steel products
Type Grade Thickness (mm) Available width range(mm) ID Density (kg/dm³) P17/50Max.Core Loss(W/kg) B8Min.Induction(T)
Common Type B23G110 0.23 700-1200 508 7.65 1.10 1.80
B27G120 0.27 1.20 1.80
B30G120 0.30 1.20 1.80
B30G130 1.30 1.80
B30G140 1.40 1.80
B35G135 0.35 1.35 1.80
B35G145 1.45 1.80
B35G155 1.55 1.80
High Induction Type B23P090 0.23 0.90 1.87
B23P095 0.95 1.87
B23P100 1.00 1.87
B27P095 0.27 0.95 1.88
B27P100 1.00 1.88
B27P110 1.10 1.88
B30P100 0.30 1.00 1.88
B30P105 1.05 1.88
B30P110 1.10 1.88
B30P120 1.20 1.88
B35P135 0.35 1.35 1.88
B35P155 1.55 1.88
Domain Refined High Induction Type B23R080 0.23 0.80 1.87
B23R085 0.85 1.87
B23R090 0.90 1.87
B27R090 0.27 0.90 1.87
B27R095 0.95 1.87
NOTE:
Detecting Basis GB/T3655-2000
P17/50 means core loss of sample per kg at max.magnetic induction 1.7T and frequency 50HZ
B8 means magnetic induction corresponding to 800A/m magnetic field intensity

Crgo Oriented Electrical Steel Grade 20r060 Used For Uhv Transformers 0

Crgo Oriented Electrical Steel Grade 20r060 Used For Uhv Transformers 1Crgo Oriented Electrical Steel Grade 20r060 Used For Uhv Transformers 2Crgo Oriented Electrical Steel Grade 20r060 Used For Uhv Transformers 3
