| MOQ: | 1 pcs |
| Price: | consult |
| Standard Packaging: | Export standard packaging |
| Delivery Period: | 5 days |
| Payment Method: | L/C, T/T, Western Union, MoneyGram |
| Supply Capacity: | 100pcs/month |
DRX Series Horizontal Transformer Winding Machine with ≤600mm Coil Diameter & ≤800mm Coil Height
My own design and manufacturing company DRX Series of horizontalwin-
ding machines, drawing on the advantages of similar products at home
and abroad, and designed and manufactured according to customers '
requirements. Horizontal winding machines in this series look unique, easy
to use, data display and intuitive, deeply user high praise. Are widely
used in power transformers, reactors and large motor manufacturing industry.
Horizontal winding machines in this series are: spindle box, trunk, base
and control components.
Main products (suitable for new energy): Foil winding machine, automatic high pressure winding machine, triangular three-dimensional core foil winding machine, amorphous
triangular three-dimensional core high and low pressure integrated automatic winding
machine, triangular three-dimensional coiling core (silicon steel, amorphous) slitting and winding machine and other transformer special production equipment; Amorphous
triangular coil core, etc
Amorphous body Assembly for non-crystalline alloy iron core transformer (referred to as non-gold) activepart Assembly and special equipment, can meet a varietyofoil-immersed and dry-type amorphous Assembly. It has changed the traditional suit of technology for the manufacture of distribution transformer and winding the lifting platform placed in the Assembly in advance, the winding axis horizontal, each wearing a single box cores into the winding holes. And core Assembly stage is complete closure, wound closed, the body of insulated Asse- mbly, clamp fastening processes. In the process, the Assembly height can easily adjust the position to meet Assembly requirements of the different working steps. This equipment movement using hydraulic systems, with smooth movements, easy to adjust, the advantage of ample power.
Hydraulic system of lifting mechanism of the Assembly include: pumps, motors, valves, to combine mod- ulesensure high reliability, low noise. Set a large lifting platforms to meet various support bodies, sliding de- vicesnecessary for space. Same time, allows sufficient redundancy and facilitate support operations. Slide the leftand right table move pulley drive, load bearing capacity, easy operation, accurate positioning. Material can be used for lifting tuning, adjusting range of 50mm, can satisfy the requirement. Plane bearing is fine-tuning settings, reduce overload adjust the intensity of operations. Fixed platform in front set screw under the drive mechanism, fixed platform, back through the crank handle operation. Platform into the work position, flipping the handle to lock the platform. Assembly on the left and right are set to help locate bodies, pressed against thebody of the length of the sides of windings, iron core, with safety function. Using screw driving structure, a single pressure on the Organization of effective stroke- 500mm. Electrical parts are brand and high reliability.
chine
