Single Layer Transformer Foil Winding Machine For 10 To 11ookv Insulators

MOQ: 1 pcs
Price: consult
Standard Packaging: Export standard packaging
Delivery Period: 5 days
Payment Method: L/C, T/T, Western Union, MoneyGram
Supply Capacity: 100pcs/month
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
JC
Certification
SGS，CE,UL
Model Number
90Q6
Document
Product Brochure PDF
Voltage::
220V
Warranty::
3 Years
After-sales Service::
3 Years
Axial Height Of Coil::
<800mm
Wire Specification::
Enameled Wire
Coil Form::
Circular, Oblong, Elliptical, Rectangular
Minimum Order Quantity:
1 pcs
Price:
consult
Packaging Details:
Export standard packaging
Delivery Time:
5 days
Payment Terms:
L/C, T/T, Western Union, MoneyGram
Supply Ability:
100pcs/month
Highlight:

foil winding machine transformer

,

transformer foil winding machine

,

foil winding in transformer

Product Description

Single Layer Foil Winding Machine for 10 to 11ookv Insulators Like Electric oil transformers

Basic Info.

Model NO.
JC-1
Model/Parameter
Jc-800
Outer Diameter of Wire Coil
< 600mm
Purpose
Suitable for Winding Circular
Transport Package
Wooden
Specification
900*900*900
Trademark
JC
Origin
China
HS Code
847981100
Production Capacity
60000PCS/Year

Product Description

Purpose:
This equipment is suitable for winding circular, elliptical, oblong, rectangular power transformers, transformers, reactances.
The control part of the device coil adopts a PLC and servo motor system, which has a high level of automation and is particularly suitable for the winding production of amorphous high-voltage coils.
Model/Parameter: JC-800

Outer diameter of wire coil: ≤ 600mm

Axial height of coil: ≤ 800mm

Coil form: circular, oblong, elliptical, rectangular

Wire specification: enameled wire( Φ 0.3 to Φ 4mm), flat wire ≤ 3x12mm

Payoff rack: double ended flat wire and a set of round wires

Payoff frame material bearing shaft: Φ 36x450mm

Winding speed: 0-280r/min

Total power: 5KWSingle Layer Transformer Foil Winding Machine For 10 To 11ookv Insulators 0
